DhanLakshmi Nira 10V (Model Code: SPV-1.0HP) is a specialized 1.0 HP (0.75 kW) Single-Phase V-Type Self-Priming Monoblock Pump engineered for deep suction lift and high vertical heads. Capable of drawing water from suction depths up to 15 meters and raising it up to 38 meters head with flows up to 3000 LPH, it features an ultra-wide 180V-240V operating voltage band, 100% electrolytic copper winding, a forged brass impeller, and a robust 15μF 440V capacitor. With built-in bi-metallic thermal protection, IP55 ingress protection, and Class B insulation, Nira 10V is ideal for areas prone to severe voltage drops and deep water sumps.
| Power Rating | 1.0 HP / 0.75 kW |
|---|---|
| Voltage Band | 180V - 240V |
| Current | 3 A |
| Supply Frequency | 50 Hz |
| Supply Phase | Single Phase (1Ø) |
| Motor Speed | 2880 RPM |
| Built-In Capacitor | 15μF 440V |
| Cooling Method | TEFC |
| Head Range | 10 - 38 Meters |
|---|---|
| Discharge Flow | 3000 - 490 LPH |
| Suction Lift | 15 Meters |
| Pipe Size | 25mm x 25mm (1" x 1") |
| Number of Stages | 1 |
| Best Efficiency Point | 27m @ 1950 LPH |
| Pump Casing | Coated Cast Iron |
|---|---|
| Impeller | Forged Brass |
| Motor Body | Extruded Aluminium |
| Stator | CRC Stamping |
| Shaft | EN8 |
| Rotor | Die-Cast Aluminium |
| Seal | Mechanical Seal |
| Winding | 100% Copper |
| Bearings | HCH ZZ |
| Insulation Class | Class B |
|---|---|
| Ingress Protection | IP 55 |
| Weight (approximate) | 10.0 kg |
| Thermal Overload Protection | Yes |
| Duty Cycle | S1 Continuous |
Engineered V-Type geometry pulls water reliably from deep underground sumps and wells down to 15 meters suction depth.
Maintains strong torque and smooth operation during severe rural and semi-urban voltage dips down to 180V.
Generates high vertical pressure up to 38 meters with an optimal Best Efficiency Point of 27m @ 1950 LPH.
Ideal for deep underground residential sumps, deep storage tanks, and wells where water level sits up to 15m below ground.
Reliably lifts water to overhead tanks in 3 to 5 story residential apartments and multi-level structures.
Specially designed to run smoothly in areas experiencing frequent low voltage drops down to 180V.
Dhanashri water pumps and motors represent precision-engineered quality and reliability. Genuine purchase is backed by our direct 12-Month Comprehensive Warranty.
